GYTA
Changrong Tech
The fibers are positioned in a loose tube made of high modulus plastic and filled with gel. Tubes (and fillers) are stranded around the metallic strength member to form the cable core filled with water blocking compound. An Aluminum tape (APL) is armored longitudinally around the core. Finally a PE jacket is extruded.
Application:
Duct / Non Self-supporting Aerial Installation
Parameter:
Counts | 2-30 | 32-36 | 38-60 | 62-72 | 74-96 | 98-120 | 122-144 | 146-216 | 218-288 |
Max.fiber counts per tube | 6 | 6 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
Units(Tubes or Fillers) | 5 | 6 | 5 | 6 | 8 | 10 | 12 | 18 | 24 |
Cable Diameter(mm) | 9.2 | 9.6 | 9.7 | 10.2 | 11.5 | 12.8 | 14.0 | 14.3 | 16.2 |
Weight(Kg/km) | 77 | 91 | 87 | 105 | 128 | 152 | 178 | 185 | 232 |
Fiber Type | G652D G655 G657 50/125 62.5/125 | ||||||||
Tensile Strength(N) | Long/Short Term:600/1500 | ||||||||
Crush Resistance(N/100mm) | Long/Short Term:300/1000 | ||||||||
Bending Radius(mm) | Static/Dynamic:10D/20D | ||||||||
Temperature(℃) | Storage /Operation:-40℃~+70℃ |
